Single chip 9 axis sensor with embedded sensor fusion that enables rapid development of sensor-enabled robotics, AR, VR, and IoT devices

The BNO085/BNO086 is a 9 axis System in Package (SiP) which enables rapid development of sensor-enabled Augmented Reality (AR), Virtual Reality (VR), Robotics and IoT devices. Co-developed by Bosch and Ceva, it features a high-performance accelerometer, magnetometer, and gyroscope with a low-power 32-bit ARM Cortex M0+ MCU in a small package. Ceva’s sensor hub software pre-integrated on the BNO085 provides exceptional 9-Axis and 6-Axis motion tracking to enable exciting sensor applications in diverse consumer and IoT products.

The BNO085 and BNO086 allow operation with application specific external software libraries provided by Ceva, such as those supporting VR controllers and fixed asset monitoring. The first such library provides additional advanced capabilities for use with VR controllers.

The BNO085/BNO086 provides application specific configurations, features, and performance in a small turn-key component that benefits OEMs through faster time-to-market, reductions in BOM cost, and the highest precision and quality.



Benefits

Powerful and highly configurable 9-axis SiP that can add precise motion sensing into any consumer application

Realize design flexibility with small SiP form factor and multiple interfaces (I2C, SPI, and UART)
Maintains sensor performance over temperature and aging affects with dynamic calibration
Fit any application requirement with output customization

Main Features

  • MotionEngine™ 9-Axis and 6-Axis Sensor Fusion
  • Dynamic calibration adjusts for accelerometer and gyroscope bias changes over factors like time and temperature
  • Application-specific features with configurable modes specialized for various use cases
  • Activity tracking with classification of walking, running, standing, in-vehicle, on-bike
  • Intelligent Power Management using activity classifiers and wake-on-motion
  • Utilize host-side libraries to add functionality in AR/VR and Attitude Monitoring
  • Flexible control via I2C, SPI or UART Interfaces
